FORM FILL SEAL (FFS)

Mr. Engineers Industries has successfully developed a fully indigenous and cost-effective version of Form-Fill-Seal (FFS) Machines, specifically designed to meet the stringent requirements of the pharmaceutical industry. Our FFS machines are built in compliance with cGMP standards and US FDA regulatory guidelines.

All product contact parts are manufactured using SS 316L, while non-contact parts are made of SS 304, ensuring hygiene and durability.

Our machines are equipped with In-Situ CIP (Cleaning-In-Place) and SIP (Sterilization-In-Place) systems, providing printed records of sterilization cycles as verifiable documentation. Integrity testing of both product and air filters is also available and can be documented.

Mr. Engineers Industries’ FFS machines are engineered to integrate the entire filling cycle in a continuous process, under a Class 100 aseptic environment, ensuring sterile production at an economical cost. Every machine is delivered with complete DQ / IQ / OQ / PQ documentation, supporting regulatory compliance and validation.

Advantages Of Mr. Engineers Industries FFS Machine

✅ No Cross Contamination

✅ Designed as per cGMP norms

✅ No Human Intervention

✅ High Sterility Assurance

✅ Easy Operation

✅ Zero Leakages

✅ In-Situ CIP/SIP Sterilization

✅ Suitable for All Types of Pharma Liquid Filling

✅ SVP: Eye Drops, Ear Drops

✅ LVP: IV Fluids, Water for Irrigation

✅ SVP Filling Range: 0.2 ml to 30 ml

✅ LVP Filling Range: 50 ml to 3000 ml

✅ Optional Nitrogen Flushing

✅ Complete Machine & Process Validation

✅ Time & Pressure Dosing (TPD)

✅ Zero Dead-Leg Valves

✅ 24×7 Online Support

Basic Features

  • Designed for SVP applications with filling range from 0.2 ml to 30 ml
  • User-friendly operation with full-color touch screen interface
  • High-speed production for enhanced output and efficiency
  • Compact and space-saving design, compliant with cGMP standards
  • Ensures zero cross-contamination with aseptic processing

Technical Features

  • All machine motions are driven by electrical servo motors for high precision and control
  • Equipped with the latest Siemens Simatic Series PLC system
  • Supports data logging, audit trail, and 21 CFR Part 11 compliance
  • Ready for data integration with SCADA, cloud storage, and external systems
  • Integrated Auto CIP/SIP system with batch reporting and sterilization printouts
  • Spacious and ergonomic design for easy maintenance and quick changeovers
  • Online monitoring of air velocity and differential pressure
  • Provision for active air sampling for cleanroom validation
  • Support for passive air sampling using an online particle counter
  • Uses ultrasonic cutter or cold knife for efficient parison cutting
  • Energy-efficient operation with minimal power usage (max. 30 units/hr)
  • Operates with low noise and minimal vibration for a smooth production environment
